Low Voltage 200w Electric Ptc Heating Element 12v For Hair Dryer Wax Warmer

Low Voltage 200w Electric Ptc Heating Element 12v For Hair Dryer Wax Warmer

    • Low Voltage 200w Electric Ptc Heating Element 12v For Hair Dryer Wax Warmer
    • Low Voltage 200w Electric Ptc Heating Element 12v For Hair Dryer Wax Warmer
  • Low Voltage 200w Electric Ptc Heating Element 12v For Hair Dryer Wax Warmer

    Product Details:

    Place of Origin: CHINA
    Brand Name: Hwalon
    Certification: CE UL
    Model Number: PR4

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000pcs
    Price: by negotiation
    Packaging Details: 1000pcs/carton
    Delivery Time: 7-10 working days
    Payment Terms: T/T, Western Union
    Supply Ability: 100,000pcs/month
    Contact Now
    Detailed Product Description
    Surface Temperature: 70℃-300℃ Power: 80-300W
    Length: 15-95mm Width: 5-45mm
    Thickness: 2.8-3.6mm Rated Voltage: 12-240V AC/DC Or Customized
    Resistance: 10Kohms Package Type: Throught Hole
    Type: Thermal Thermistor



    Low Voltage 200w Electric Ptc Heating Element 12v For Hair Dryer Wax Warmer



    PTC heating elements:



    1. It can control the temperature by itself.

    2. The lifetime is longer.

    3. It could give out the heater continous.

    4. saving energy

    5. The power is stable.



    Operating voltage

    12-240V AC/DC or customized

    Heating element

    PTC resistor, temperature limiting

    Heater body

    aluminium, anodised

    Mounting

    screw fixing

    Fitting position

    variable

    Operating temperature

    -45 to +70 °C (-49 to +158 °F)

    Operating/Storage humidity

    max. 90 % RH (non-condensing)



    Typical Applications:



    1. Heater fan

    2. Heating Plates

    3. Drying Machines

    4. Hair Dryer

    5. Foot Warmer

    6. Diesel Heater

    7. Hot melt glue gun





    Dimentions:




    Parameters of battery powered heating element :



    Length Width Thickness Surface temperature Withstand Voltage Rate
    /mm /mm /mm /°C /V voltage
    30 13 3.3 250 3750 100~240
    48 10 3.2 255 3750 100~240
    60 15 3.2 255 3750 100~240
    60 13 3.2 260 3750 100~240
    60 13 3.2 260 3750 100~120
    24 15 3.2 260 3750 100~240
    48 15 3.2 260 3750

    100~240





    Notice :


    1. Working Voltage rang: 12-240V AC/DC or customized
    2. Surface Temperature: 70°C~300°C , the temperature tolerance less than ±5°C.
    3. The lead wire, fiber glass sleeve, insulate film and shells can customized according to per customers requirements.



    Unlike traditional heating elements that use a resistance wire such as Nichrome to generate heat,PTC heating elements are made as ceramic stones, ase on barium titanate.

    They have unique characteristics as semeconductors and their ferro-electric propertise can be precisely determined during their design.


    How to Order:

    1. Application of the PTC heater : _______
    2. Working environment of the PTC heater :______
    3. The range of operating temperature:___℃to ____℃
    *4. Dimension of the PTC heater: _______
    *5. R(25) Value :_____
    *6. Surface Temperature:_____
    *7. Power:_____

    * Fill “*” items necessarily
