Lighting Arrester MOV Electronic Component High Temperature 10D431K 430V
  • name
  • name

Lighting Arrester MOV Electronic Component High Temperature 10D431K 430V

MOQ: 10000pcs
Standard Packaging: 250pcs/bag
Supply Capacity: 100,000,000pcs/month
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
MOV
Certification
UL,VDE,CSA
Model Number
10D431K
Certification:
UL,VDE,CSA
Brand:
MOV Or ZOV
Operating Temp.:
-40~85 Degree
AC Voltage:
275V
DC Voltage:
350V
Varistor Voltage:
430V
Highlight:

MOV electronic component

,

MOV electrical component

Product Description

Lighting Arrester MOV Electronic Component High Temperature 10D431K 430V


Metal oxide varistor is the core of the arrester,which main component is Zinc Oxide and with a small quantity of bismuth oxide, fluoride oxide, manganous carbonate, antimony oxide and other gleam of additive and made with high temperature.

Specification of Metal Oxide Varistor MOV 10D431K:


P/N10D431K
Size10mm
AC voltage275V
DC Voltage350V
Varistor Voltage430V(387-473)
Max Clamping Voltage/Current775V/25A
Max Peak Current(1 time)2500A
Max Peak Current(2 times)1250A
Capacitance150pf


Description of Metal Oxide Varistor 10mm series:


P/NAC VoltageDC VoltageVaristor VoltageUL
10D180L111418(15-21)√
10D220K141822(20-24)√
10D270K172227(24-30)√
10D330K202633(30-36)√
10D390K253139(35-43)√
10D470K303847(42-52)√
10D560K354556(50-62)√
10D680K405668(61-75)√
10D820K506282(74-90)√
10D101K6085100(90-110)√
10D121K75100120(108-132)√
10D151K95125150(135-165)√
10D181K115150180(162-198)√
10D201K130170200(185-225)√
10D221K140180220(198-242)√
10D241K150200240(216-264)√
10D271K175225270(243-297)√
10D301K190250300(270-330)√
10D331K210275330(297-363)√
10D361K230300360(324-396)√
10D391K250320390(351-429)√
10D431K275350430(387-473)√
10D471K300385470(423-517)√
10D511K320415510(459-561)√
10D561K350460560(504-616)√
10D621K385505620(558-682)√
10D681K420560680(612-748)√
10D751K460615750(675-825)√
10D781K485640780(702-858)√
10D821K510670820(738-902)√
10D911K550745910(819-1001)√
10D102K6258251000(900-1100)√
10D112K6808951100(990-1210)√



Application of Metal Oxide Varistor:

Surge Protector Device,Motor Protector,Over-voltage Protector Device and Lightning Arrester ,etc

Competitive Advantage of Hwalon Metal Oxide Varistor :
1. Radial leaded type
2. Many size choose 7mm, 10mm, 14mm, 20mm , 25mm and 32mm
3. VM(AC)RMS voltage range from 130V to 1000V
4. Energy absorption capability up to 360J
5. UL ,VDE ,CSA Certification

RFQ:

 QuestionAnswers
1What is the MOQ?5000pcs.
2What is the payment terms?Negotiation.
3Can you accept special requirement?Yes,we can.We can design for your special requirement.
4Can you make the printing artworks(such as user manual/packing/rating label) in our languageYes,we can.We do OEM for a long time
5Can we order samples:Yes ,you can . Free samples are available
