Paper Type Insulated Electric Heating Resistor, 100 V - 240 V Electric Heating Element For Foot Warmer
  • name
  • name

Paper Type Insulated Electric Heating Resistor, 100 V - 240 V Electric Heating Element For Foot Warmer

MOQ: 1000pcs
Price: negotiation
Standard Packaging: 1000pcs / carton
Delivery Period: 5 - 7 working days
Payment Method: T/T, Western Union, Paypal
Supply Capacity: 100,000,pcs / month
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
Hwalon
Certification
CE
Model Number
PR4
Material:
Ceramic
Function:
Heating
Surface Temperature:
70 - 300 Degree
Resistance:
1 - 100Kohm
Warranty:
One Year
Size:
You Can Choose
Application:
Hairdressing Equipment
Power:
100W
Voltage:
100 - 240v
Price:
Factory Price
Highlight:

ceramic PTC heater

,

ceramic resistor heater

Product Description

Paper type insulated electric heating resistor 100v - 240v heating element for Foot Warmer

Product introduction

Paper type insulated heating element is a new type of surface heating PTC heating element in the ordinary PTC components on both sides of the installation of a pair of lead wire metal wire, and then the appearance of the metal electrode insulated yellow paper, simple structure; no additional control Temperature device can be constant temperature heating and high insulation strength, safe and reliable, sustainable heating power and stability, the use of a wide range of voltage, long life, the other flexible and diverse dimensions, according to the actual needs of customers build various models specifications.

Features

1. low cost solution
2. safety × high reliability.
2. effective constant temperature
3. the use of safe, non-burning
4. automatic temperature control

Specification


Length / mm

Width / mm

Thickness / mm

Surface temperature
/°C

Withstand Voltage / V

Rate voltage

24

15

3.3

180

3750

100 - 240

70

13

3.3

190

3750

100 - 240

60

13

3.3

220

3750

100 - 240

35

10

3.3

220

3750

100 - 240


Notice

1. Parallel connection is necessary for two or more PTC connection.
2. Our PTC products are high reliable, long lifetime, but if they are assembled improperly, the power or temperature may be instable.
3. The surface temperature of PTC heating element can be controlled by itself, control circuit may be
omitted in most appliances.

Applications

1. Heater fan
2. Heating Plates
3. Drying Machines
4. Hair Dryer
5. Foot Warmer
6. Diesel Heater
7. Hot melt glue gun

Company information

Hwalon Electronic Limited with 15 years experience on NTC temperature sensor field.
1. Competitive price
2. On time handle over
3. Competitive price
4. Inquiry answered in 24hrs
5. Good team waiting here to serve for you
6. RoHS × UL compatible
7. OEM × ODM business accept
8. Main Market:Europe,North America,Asia

How to Order

1. Application of the PTC heater  _______
2. Working environment of the PTC heater  _____
3. The range of operating temperature:___℃ to ____℃
×4. Dimension of the PTC heater: _______
×5. R(25) Value _____
×6. Surface Temperature_____
×7. Rated Voltage ____
×8. Need insulated or not _____
× Fill “×” items necessarily

FAQ




Question

Answers
1

What is the MOQ?

1000pcs.
2

What is the payment terms?

Negotiation.
3

Can you accept special requirement?

Yes,we can. We can design for
 your special requirement.
4

Can you make the printing artworks
(such as user manual / packing / rating label) in our language

Yes, we can. We do OEM work for
 long time
5

Can we order samples:

Yes, you can. Free samples are
 available


Paper Type Insulated Electric Heating Resistor, 100 V - 240 V Electric Heating Element For Foot Warmer 0

Tags:

ceramic PTC heater,

ceramic resistor heater,

ptc thermistor heater
